ATO1B420
Model details
ATO-5-B420-D10/SP4 4m cable output
Bipolar 5 A AC nominal, Split core, 10 mm diameter, DC RMS 4~20mA output, 4 meter cable output, with DIN Rail adapter
- Series
-
ATO1B420
- Measurement
-
Current
- Nominal Value
-
5 A
- Measuring Range
-
6 A
- Second. Nominal Signal
-
Current
- Second. Nominal Signal Value
- DC RMS 4-20mA
- Primary Signal
-
AC
- Supply Voltage
-
External DC Unipolar
- Supply Voltage Range
- 20 - 28 V
- Accuracy
- 1.5 %
- Op. Temperature
- -10 °C / 55 °C
- Technology
-
Current Transformer
- Mounting
-
DIN rail
- Applications
-
AutomationDrivesPower SuppliesRenewable EnergiesSmart GridWelding
FRONT
BACK
LEFT
RIGHT
Download
